THE TOYOTA CORE IC CUSHION FORKLIFT. The one that put Toyota forklifts on the map is the one to depend on to get it done — whatever your “it” is.
Products
Core IC Cushion Forklift
Toyota’s Core IC Cushion Forklift is one of the most popular forklifts in North America. Warehousing and distribution applications, the auto industry, general manufacturing plants, and retail storefronts often utilize Toyota’s Core IC Cushion for its extreme versatility. Powerful enough to lift up to 6,500 lbs. yet capable of navigating in 12-foot aisles, the Core IC Cushion forklift is a trusted multipurpose forklift.
Special Features
- 3,000-6,500 lb. Lifting Capacity
- System of Active Stability (SAS)™
- SEnS Smart Environment Sensor® Compatible
Versatility to Get Things Done
At Toyota, we know your operation is facing the challenge of increasing demands and need forklifts that thrive, even with additional use. Toyota’s Core IC Cushion Forklift is an industry-leading, multi-use forklift. Toyota’s innovative System of Active Stability (SAS)™ comes standard on all Core IC Cushion models.
CORE IC CUSHION FORKLIFT FEATURES
Master of the Inside Game
Strong horsepower and a compact design. It’s a winning combination that makes the Core IC Cushion Forklift not only a popular choice for nearly all indoor applications but one of the top-selling forklifts, period. A compact chassis teamed up with a tight turning radius maximizes maneuverability throughout the warehouse, allowing operators to lift up to 6,500 pounds and still nimbly navigate 12-foot aisles.
Visibly Better
Forward, up, back. Any way you look, operators appreciate the clear, open sight lines of the Core IC Cushion. Mast hosing is tucked away, overhead guard bars are oriented for maximum visibility, and the mast crossmember doesn’t block your view of the fork tips. The standard LCD multifunction display, conveniently located on the dash, features QR code diagnostics for ease of access to operational and performance data.
Ease of Service
Legendary Toyota quality means more productivity over the lifecycle of your forklift, along with lower repair costs. The Core IC Cushion Forklift provides several service features. These features include:
- Easy-access, no tools required floorboard
- Engine hood assist damper with lock
- Externally mounted hydraulic oil return filter
- Air cleaner discharge valve
- Easy-lift engine hood
- Exclusive QR code diagnostics
CORE IC CUSHION FORKLIFT
| Model | Load Capacity (lbs.) | Max Travel Speed Full Load (MPH) | Max Lift Speed Full Load (FPM) | Max Gradeability Full Load (%) | Basic Right Angle Stack (in.) |
| 40-8FGCU20 | 4,000 | 10.6 | 120 | 35 | 92.3 |
| 40-8FGCU25 | 5,000 | 10.6 | 120 | 30 | 94.3 |
| 40-8FGCU30 | 6,000 | 10.6 | 98 | 24 | 97.5 |
| 40-8FGCU32 | 6,500 | 10.6 | 98 | 24 | 98.8 |
| 50-8FGCSU20 | 4,000 | 10.9 | 110 | 35 | 87.6 |
| 50-8FGCU15 | 3,000 | 10.9 | 110 | 43 | 83.5 |
| 50-8FGCU18 | 3,500 | 10.9 | 110 | 40 | 86 |
| 50-8FGCU25 | 5,000 | 10.6 | 120 | 30 | 94.3 |
| 50-8FGCU30 | 6,000 | 10.6 | 98 | 24 | 97.5 |
| 50-8FGCU32 | 6,500 | 10.6 | 98 | 24 | 98.8 |
| 50-8FGCU20 | 4,000 | 10.6 | 120 | 35 | 92.3 |
* Based on 24″ Load center ** Add load length and clearance
| Model Number | 8FGCSU20, 8FGCU15-32 |
|---|---|
| Load Capacity | 6,500 |
| Max Travel Speed Full Load | 10.9 |
