The Aichi E-Series Scissor Lift. These machines are engineered to be durable and easy to use. They are loaded with features to tackle your unique tasks and keep your people and equipment working harder, longer.
Products
Aichi Scissor Lift
The AICHI E-Series Scissor Lifts can easily be used for multiple purposes between facilities maintenance, construction, plumbing, painting, and more. The E-Series Scissor Lifts can fit through a standard doorway and can reach working heights of 25, 26, 32, and 38 feet.
SPECIAL FEATURES
- 25 ft.-38 ft. Working Heights
- 24 V AC Drive System
- Zero-Degree Turning Radius
Cutting Edge Performance
The AICHI E-Series Scissor Lifts are engineered to be durable and easy to use. They are loaded with features to tackle your unique challenges and to help make your teams as productive as possible. Thoughtful engineering and versatility make these electric scissor lifts a dependable versatile lifting solution. And, with an efficient AC Drive Motor and robust construction, the AICHI E-Series Scissor Lift is applicable to a wide variety of indoor and outdoor applications.
AICHI Scissor Lift Features
Roll-Out Platform Extension Deck
This standard feature makes it easy to reach across objects on all AICHI E-Series Scissor Lift models. The extension adds a minimum of
35.4 inches to your working space with up to 50 inches of additional reach on larger models. The extension platform is easy to use and controlled with user-friendly handles that lock into place for secure operation.
High Access, Safe Operation
The AICHI E-Series Scissor Lift offers carefully engineered for operator confidence. From its anti-rollback function to speed reduction with an elevated work platform, AICHI will help reduce the risk for operators. A pothole protection system can further stabilize the operator’s working platform. Additionally, these machines are equipped with a travel alarm, horn, and excellent visibility in most typical working environments.
Access to Interior Areas
The 1932E model, the smallest and most nimble AICHI Scissor Lift, that can fit through a standard doorway of 80” x 34” with fixed guardrails, making it a powerful ally for your facility maintenance needs. Larger models feature standard fold-down guardrails and a thoughtful design of the detachable control box and cable, so you can adapt to your working space.
Aichi Scissor Lift
| Model | Platform Height (ft.) | Platform Capacity At Lift Height | Platform Lift Time (sec.) | Platform Lower Time (sec.) | Overall Width (in.) |
| SV1932E | 19 | 505 lbs. at 228 in. | 26 | 30 | 32.1 |
| SV2032E | 20 | 790 lbs. at 240 in. | 28 | 40 | 31.9 |
| SV2632E | 26 | 505 lbs. at 307 in. 795 lbs. at 236 in. | 33 | 37 | 31.9 |
| SV2646E | 26 | 705 lbs. at 382 in. 990 lbs. at 311 in. | 40 | 50 | 46.1 |
| SV3246E | 32 | 705 lbs. at 382 in. 990 lbs. at 311 in. | 55 | 60 | 46.1 |
* Based on 24″ Load center ** Add load length and clearance
| Platform Height | Platform Height: 19 Feet | $12,799, Platform Height: 20 Feet | $14,799, Platform Height: 26 Feet | $16,799, Platform Height: 26 Feet | $16,999, Platform Height: 32 Feet | $22,399 |
|---|
